| Model | ZLD-1 | ZLD -3 | ZLD -6 | ZLD -10 | ZLD -12 | ZLD -15 | ZLD -20 | ZLD -30 | ZLD -40 | ZLD -60 | ZLD -80 | ZLD -100 | ZLD -150 | ZLD -200 | |
| Air Flow Rate(Nm³/min) | 1 | 3 | 6 | 10 | 12 | 15 | 20 | 30 | 40 | 60 | 80 | 100 | 150 | 200 | |
| Air Connection Pipe Diameter DN(mm) | 25 | 32 | 40 | 50 | 50 | 65 | 65 | 80 | 100 | 125 | 100 | 100 | 200 | 200 | |
| Power Supply | AC220V/50Hz | ||||||||||||||
| Outline Dimension（mm) | Length | 960 | 1090 | 1360 | 1360 | 1440 | 1600 | 1920 | 1940 | 2200 | 2010 | 2320 | 2600 | 2800 | 3000 |
| Width | 380 | 420 | 610 | 610 | 700 | 800 | 850 | 880 | 990 | 1000 | 1000 | 1010 | 1200 | 1350 | |
| Height | 1300 | 1300 | 1580 | 1780 | 2000 | 2150 | 2290 | 2550 | 2660 | 2850 | 3250 | 3080 | 3210 | 3300 | |
| Inlet Height | 110 | 160 | 210 | 210 | 230 | 240 | 240 | 240 | 280 | 360 | 360 | 360 | 400 | 400 | |
| Outlet Height | 1210 | 1210 | 1500 | 1700 | 1930 | 2040 | 2200 | 2400 | 2550 | 2750 | 3100 | 3000 | 3120 | 3250 | |
| Net Weight of the Equipment (kg) | 270 | 510 | 670 | 840 | 900 | 980 | 1380 | 1810 | 2300 | 2700 | 3350 | 4300 | 5500 | 6350 | |
